china ul10064 awg 32 fep pfa ptfe etfe insulated wire 150C 30V manufacturer

UL10064

Item Number:UL10064

Rated voltage: 30V
Working temperature: -40～+150℃
Color: red/yellow/blue/white/black/yellow-green/brown, etc.
Conductor: solid core or stranded TC/silver-plated copper wire
Insulation: FEP

Ratings/Approvals:

150°C – 30 Volts – UL758, UL1581
UL VW-1 Flame Rated
RoHS Compliant

Construction:

Conductors
40 AWG minimum
Solid or Stranded tinned copper, bare copper or silver-plated copper
(Other conductor materials available)

Insulating System
FEP/PFA/PTFE/ETFE insulation

Standard Color Coding
Available in Colors or Striped Combinations

Characteristics:

High temperature products:
- Temperature resistance 150 degrees
- Oil resistance, acid, and alkali resistance
- Virtually eliminates skin irritation
- Color stable at elevated temperatures
- Low Smoke Zero Halogen
Suitable for UV, ozone, or moisture exposure
Suited for liquid-immersed applications
Suitable for applications to -40°C

UL10064

Part No.	Temp Rating	Voltage Rating	Awg. Size	# Strands	Final O.D. (in)	Final O.D. (mm)	Wgt. (lbs/ Mft)	Wgt. (kg/km)	Min.Bend Radius (in)	UL	CSA
10064	105C	30V	22	7	0.08	2.03	5	7.44	0.64	1581	AWM I A/B FT1
10064	105C	30V	20	7	0.087	2.21	6	8.93	0.7	1581	AWM I A/B FT1
10064	105C	30V	18	16	0.096	2.44	8	11.91	0.77	1581	AWM I A/B FT1
10064	105C	30V	16	7	0.108	2.74	11.64	17.32	0.86	1581	AWM I A/B FT1
10064	105C	30V	14	41	0.12	3.05	16.8	25	0.96	1581	AWM I A/B FT1
10064	105C	30V	12	65	0.137	3.48	25.08	37.32	1.1	1581	AWM I A/B FT1
10064	105C	30V	10	105	0.166	4.22	38.92	57.92	1.33	1581	AWM I A/B FT1
10064	105C	30V	8	133	0.231	5.87	64.35	95.77	1.85	1581	AWM I A/B FT1
10064	105C	30V	6	133	0.307	7.8	105.32	156.74	2.46	1581	AWM I A/B FT1

Description

What is the UL10064 wire?

UL10064 is a kind of Teflon wire, the insulation of ul10064 can be ETFE, FEP, PFA, or PTFE. ul10064 is a very thin Teflon high temperature wire, which can reach a minimum of 36AWG. ADS Cable is a famous manufacturer in China produces ul10064 PTFE wire, we can OEM the insulation of the UL10064 for you, and also the size, like ul10064 awg 32, ul10064 awg 30, and ul10064 awg 34.
