UL1180
UL1180
Item Number:UL1180
- Rated voltage: 300V
- Working temperature: -40～+200℃
- Color: red/yellow/blue/white/black/yellow-green/brown, etc.
- Conductor: solid core or stranded nickel plated copper/tinned copper/silver-plated copper wire
- Insulation: PTFE
Ratings/Approvals:
200°C – 300 Volts
RoHS Compliant
Construction:
Conductors
32 AWG - 10 AWG
Solid or Stranded tinned copper, nickel-plated copper, or silver-plated copper
(Other conductor materials available)
Insulating System
PTFE insulation
Standard Color Coding
Available in Colors or Striped Combinations
Characteristics:
- High temperature products:
- Temperature resistance 200 degrees
- Oil resistance, acid, and alkali resistance
- Virtually eliminates skin irritation
- Color stable at elevated temperatures
- Low Smoke Zero Halogen
- Suitable for UV, ozone, or moisture exposure
- Suited for liquid-immersed applications
- Suitable for applications to -40°C
Categories
UL1180
| Part No. | Temp Rating | Voltage Rating | Awg. Size | # Strands | Final O.D. (in) | Final O.D. (mm) | Wgt. (lbs/ Mft) | Wgt. (kg/km) | Min.Bend Radius (in) | UL | CSA |
| 1180 | 200C | 300V | 22 | 7 | 0.08 | 2.03 | 5 | 7.44 | 0.64 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 20 | 7 | 0.087 | 2.21 | 6 | 8.93 | 0.7 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 18 | 16 | 0.096 | 2.44 | 8 | 11.91 | 0.77 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 16 | 7 | 0.108 | 2.74 | 11.64 | 17.32 | 0.86 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 14 | 41 | 0.12 | 3.05 | 16.8 | 25 | 0.96 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 12 | 65 | 0.137 | 3.48 | 25.08 | 37.32 | 1.1 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 10 | 105 | 0.166 | 4.22 | 38.92 | 57.92 | 1.33 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 8 | 133 | 0.231 | 5.87 | 64.35 | 95.77 | 1.85 | 758 | AWM I A/B FT1 |
| 1180 | 200C | 300V | 6 | 133 | 0.307 | 7.8 | 105.32 | 156.74 | 2.46 | 758 | AWM I A/B FT1 |
Description
What is the UL1180 wire?
UL1180 wire is one kind of PTFE insulated wire, UL1180 is a single conductor with PTFE extruded insulation, Its temperature resistance is 200 degrees, and its voltage resistance is 300V, the size of the UL1180 wire is from 32AWG to 10AWG, It is used for internal connection wires of electrical equipment.
